Description
The Cablecraft CMA12583H Green 9-Pin Push-On Protective Cap is designed for OEM and industrial applications where exposed 9-pin electrical connector interfaces require reliable protection during assembly, shipment, storage, operation, or service.
This push-on cap helps cover compatible 9-pin connector openings to reduce exposure to debris, incidental contact, and environmental contamination. The integrated molded tether includes a small mounting hole, allowing the cap to remain secured near the connector when removed. This helps reduce misplaced caps and supports easier service access in production or field environments.
The CMA12583H is molded in green material and includes raised OBD lettering for quick visual identification. The drawing specifies TPE material with natural and green colorant or Sarlink 4175N, with a 75 durometer note. Its push-on design supports quick installation without threaded engagement, tools, or additional fastening hardware.
Cablecraft supports quote-based sourcing for protective electrical caps, connector accessories, motion control assemblies, and OEM component supply programs.
Request A Quote
Key Benefits
- Protects 9-pin connector interfaces
Helps shield exposed electrical connector openings from dust, debris, contamination, and handling damage. - Green visual identification
Green molded construction supports quick recognition in production, service, and equipment environments. - Raised OBD lettering
Molded OBD markings help identify the cap’s intended connector application. - Push-on installation
Designed for fast installation without threads, tools, or separate fastening hardware. - Integrated retention tether
Molded tether with small mounting hole helps keep the cap near the connector when removed. - OEM application support
Well suited for quote-based sourcing, replacement part programs, and production supply requirements.
Product Specifications
| Specification | Detail |
|---|---|
| Cablecraft Part Number | CMA12583H |
| OEM Cross-Reference P/N | GN5M510800 |
| Product Type | 9-Pin Push-On Protective Cap |
| Connector Style | 9-pin electrical connector protective cap |
| Installation Type | Push-on |
| Color | Green |
| Identification Marking | Raised OBD lettering |
| Material | TPE, natural + green colorant, or Sarlink 4175N per drawing note |
| Durometer | 75 Shore |
| Retention Feature | Integrated molded tether with small mounting hole |
| Cap Outer Diameter | Approx. 1.45 in. |
| Cap Inner Diameter | Approx. 1.25 in. |
| Cap Height | Approx. 0.72 in. |
| Tether / Strap Length | Approx. 3.375 in. ± 0.125 in. |
| Tether End Feature | Small mounting hole |
| Pricing | Request a quote |
| Shipping | Quoted based on order requirements |
Request A Quote
FAQ
What is the Cablecraft CMA12583H used for?
The Cablecraft CMA12583H is a green push-on protective cap used to cover and protect compatible 9-pin electrical connector interfaces when the connector is not in use.
Does the CMA12583H cap include OBD markings?
Yes. The cap includes raised OBD lettering for visual identification.
Does this cap include a retention feature?
Yes. The CMA12583H includes an integrated molded retention tether with a small mounting hole to help keep the cap near the connector when removed.
What material is the CMA12583H cap made from?
The drawing specifies TPE with natural and green colorant or Sarlink 4175N, with a 75 durometer note.
Is pricing shown online?
No. This product should be set up as quote-based. Customers can request pricing, availability, and order details through Cablecraft.
Can Cablecraft support OEM production requirements?
Yes. Cablecraft supports OEM customers with application review, sourcing support, and production supply for electrical caps, connectors, and engineered component solutions.
