Description
The Cablecraft CMA12579H 9-Pin Push-On Protective Cap is designed for OEM and industrial applications where exposed electrical connector interfaces need reliable protection during storage, shipment, assembly, operation, or service.
This push-on cap helps cover and protect compatible 9-pin connector openings from dirt, debris, and incidental contact. Its molded tether design allows the cap to remain attached near the connector when removed, helping reduce the chance of misplaced caps during equipment maintenance or production handling.
The CMA12579H is specified as a black molded TPE cap with material options noted as Santoprene 111-73 or Sarlink X-5775B4, depending on approved application requirements. With a simple push-on installation style, this cap is well suited for production environments, replacement part programs, and OEM connector protection applications.
Cablecraft supports quote-based sourcing for protective electrical caps, connector accessories, motion control assemblies, and engineered component solutions for OEM customers.
Request A Quote
Key Benefits
- Protects 9-pin connector interfaces
Helps shield exposed electrical connector openings from dust, debris, and handling damage. - Push-on cap design
Simple installation without threaded engagement or additional tooling. - Integrated retention tether
Molded strap with small mounting hole helps keep the cap near the connector when removed. - Durable molded material
Specified in black TPE, with Santoprene 111-73 or Sarlink X-5775B4 material options noted on the drawing. - OEM application support
Designed for quote-based sourcing, replacement part programs, and production supply needs.
Product Specifications
| Specification | Detail |
|---|---|
| Cablecraft Part Number | CMA12579H |
| OEM Cross-Reference P/N | 005M489800 |
| Product Type | 9-Pin Push-On Protective Cap |
| Connector Style | 9-pin electrical connector protective cap |
| Installation Type | Push-on |
| Material | TPE, black, or Santoprene 111-73 / Sarlink X-5775B4 per drawing note |
| Durometer | 73 to 75 Shore |
| Color | Black |
| Retention Feature | Molded tether with small mounting hole |
| Cap Outer Diameter | Approx. 1.45 in. |
| Cap Inner Diameter | Approx. 1.25 in. |
| Cap Height | Approx. 0.72 in. |
| Tether Length | Approx. 3.375 in. ± 0.125 in. |
| Pricing | Request a quote |
| Shipping | Quoted based on order requirements |
Request A Quote
FAQ
What is the Cablecraft CMA12579H used for?
The Cablecraft CMA12579H is a push-on protective cap used to cover and protect compatible 9-pin electrical connector interfaces when the connector is not in use.
Does the CMA12579H cap include a tether?
Yes. This cap includes an integrated molded retention tether with a small mounting hole.
What material is the CMA12579H cap made from?
The drawing specifies black TPE, with Santoprene 111-73 or Sarlink X-5775B4 listed as approved material options.
Is this product available for online purchase?
This product should be set up as a quote-based product. Customers can request pricing, availability, and order details through Cablecraft.
Can Cablecraft support OEM production requirements?
Yes. Cablecraft supports OEM customers with application review, sourcing support, and production supply for electrical caps, connectors, and engineered component solutions.
